Note that you can also find this new option in the Wipeout command. No more turning wipeout frames on and off! Just set the new WIPEOUTFRAME system variable to 2, and the frame displays but won't plot. To edit a wipeout, the frame must display, but often we don't want that frame to plot. The Mleader text box also includes a margin between the text and the frame now, as well as a minimum width for the text to prevent text overflow.Įasily move leaders to the front of the display with the new Leader option in TextToFront. Now, it's easy to put your leaders in front of other objects with the new Leader option in the TextToFront tool. Consequently, you will burn fewer calories with AutoCAD 2013. At last, the font list window has been lengthened, so you won't have to do as much scrolling. I'm sure that in the early days of AutoCAD, a short font window in the Text Style dialog box wasn't a problem after all, there were fewer than half a dozen fonts! Over time, that list grew substantially - but the teeny, tiny window for the font list did not. It's easier to identify the current drawing and layout in Quick View Drawings. Now you don't have an excuse not to use this nifty command! AutoCAD 2013 displays the current drawing more clearly with bold text and a nice green border.
#How to migrate a specific tool palette in autocad 2013 free#
Feel free to select as many hatch objects as you want!ĭo you use Quick View Drawings to move from one open drawing to another? Well, you should! Quick View Drawings (found on the status bar) helps you easily move to another open drawing, as well as a specific layout tab of that drawing. There was a problem, however: You could only edit one hatch at a time.
This new feature should help you make more accurate property selections.Īutodesk moved the Hatch Editor to a contextual tab on the ribbon a couple of releases ago. For example, as you scroll down the Layer pull-down list with objects highlighted, you can see the object properties change for each layer as you move your cursor. Now, the new In-Canvas Property Preview lets you see the changes before you finalize them.
Use the new Strikethrough text tool to draw a line through your text.īefore AutoCAD 2013, most property modifications (such as layer, color, and linetype) didn't appear until after they were changed. Mtext (along with tables, mleaders, and dimensions) now supports the common text feature of strikethrough text. In many cases, if someone doesn't mention them, you just might miss them - and we certainly wouldn't want that! Following are eleven of my favorite new features. Exposing Hidden Gems in AutoCAD 2013 18 Jul, 2012 By: Lynn Allen Circles and Lines Tutorial: Eleven little productivity enhancements add up to big time savings.Īnother release of AutoCAD is here - and as usual, I prefer to write about the unsung heroes in the product, those smaller features that will no doubt improve your everyday drawing life.
